Analysis of mutations of Plasmodium falciparum multidrug resistance gene 1 and K13 gene in imported Plasmodium falciparum in Henan Province

Abstract

Abstract:

Objective To identify mutations of Plasmodium falciparum multidrug resistance gene 1 （Pfmdr1） and K13 gene in imported P. falciparum in Henan Province during 2013-2015. Methods Blood samples and epidemiological information were collected from 386 workers returning from Africa, who were diagnosed as imported falciparum malaria in Henan Province during 2013-2015. Plasmodium DNA was extracted, followed by nested PCR to amplify the Pfmdr1 and K13 gene. The PCR products were sequenced and sequence alignment was carried out to analyze gene mutations. Results The 386 patients returned from 26 African countries and were predominantly males. The top 3 disease-exporting counties were Angola (22.5%, 87/386), Equatorial Guinea (13.7%, 53/386), and Nigeria (13.2%, 51/386). Pfmdr1 and K13 genes were amplified from all the 386 blood samples. Sequencing results indicated mutation rate of 23.6% (91/386) and 3.1% (12/386) at loci 86 and 1246 of Pfmdr1, respectively, and 5.4% (21/386) for K13 gene. The 21 blood samples with K13 gene mutations were from 10 countries, in which no C580Y mutation was found, but the R539T and P574L mutations (0.3%, 1/386 for each), which are associated with artemisinin resistance, were found in samples from Angola and Equatorial Guinea. The mutation rate for Pfmdr1 locus 86 was 28.8% (36/125), 23.4% (32/137) and 18.6% (23/124) in each year during 2013-2015, respectively (χ² = 6.438, P < 0.05), and that for locus 1246 was 4.0% (5/125), 3.7% (5/137), 1.6% (2/124), respectively (χ² = 1.384, P > 0.05). The mutation rate of K13 gene was 3.2% (4/125), 8.8% (12/137) and 4.0% (5/124) in each year during 2013-2015, respectively (χ² = 4.631, P > 0.05). Conclusion The mutation rate at loci 86 and 1246 of Pfmdr1 is 23.6% (91/386) and 3.1% (12/386), respectively, and that of K13 gene was 5.4% (21/386). Besides, two mutations R539T and P574L associated with artemisinin resistance are detected.

Key words: Imported malaria, Plasmodium falciparum, Plasmodium falciparum multidrug resistance gene 1, K13 gene, Mutation

CLC Number:

R382.312

Cheng-yun YANG, Su-hua LI, Ya-lan ZHANG, Rui-min ZHOU, Ying LIU, Dan QIAN, Yu-ling ZHAO, Bian-li XU, Hong-wei ZHANG, Yan DENG. Analysis of mutations of Plasmodium falciparum multidrug resistance gene 1 and K13 gene in imported Plasmodium falciparum in Henan Province[J]. CHINESE JOURNAL OF PARASITOLOGY AND PARASITIC DISEASES, 2018, 36(2): 97-102.

Figures/Tables 4

Table 1

Fig. 1

Table 2

Mutation distribution of Plasmodium falciparum multidrug resistance gene 1 and K13 gene in imported P. falciparum in Henan Province

基因 Gene	突变位点 Mutation position	突变病例数 No. cases with mutation	来源国（病例数） Source country （No. cases）
K13	R471R	2	安哥拉Angola（2）
	R539T	1	安哥拉Angola（1）
	M579I	1	安哥拉Angola（1）
	Q613E	2	安哥拉Angola（1）, 刚果金Congo, DRC （1）
	N664D	1	津巴布韦Zimbabwe （1）
	A578S	2	乌干达Uganda （1）, 几内亚Guinea （1）
	F662C/N664D	1	贝宁Benin （1）
	N629S	1	利比里亚Liberia （1）
	E556K/D648Y	1	塞拉利昂Sierra Leone （1）
	G496G	1	尼日利亚Nigeria （1）
	K610R	1	尼日利亚Nigeria （1）
	P574L	1	赤道几内亚Equatorial Guinea （1）
	M476I/V589I	1	赤道几内亚Equatorial Guinea （1）
	L663V	1	赤道几内亚Equatorial Guinea （1）
	K658Q	1	赤道几内亚Equatorial Guinea （1）
	A578T/M579I	1	赤道几内亚Equatorial Guinea （1）
	D464N	1	赤道几内亚Equatorial Guinea （1）
	N664N	1	赤道几内亚Equatorial Guinea （1）
Pfmdr1	86位点 Locus 86	91	尼日利亚Nigeria （11）, 苏丹Sudan （2）, 利比亚Libya （2）, 赞比亚Zambia （2）, 安哥拉Angola（11）, 肯尼亚Kenya （1）, 坦桑尼亚Tanzania（1）, 乍得Chad（1）, 马里Mali（1）, 多哥Togo （2）, 贝宁Benin （1）, 喀麦隆Cameroon （7）, 加蓬Gabon （2）, 赤道几内亚Equatorial Guinea （20）, 刚果金Congo, DRC （2）, 刚果布Congo （1）, 利比里亚Liberia （10）, 加纳Ghana （1）, 塞拉利昂Sierra Leone （4）, 几内亚Guinea （8）
	1246位点 Locus 1246	12	利比亚Libya （2）, 肯尼亚Kenya （1）, 利比里亚Liberia （3）, 刚果金Congo, DRC （1）, 喀麦隆Cameroon （2）, 塞拉利昂Sierra Leone （1）, 安哥拉Angola（1）
	86/1246位点 Locus 86/1246	11	利比亚Libya （2）, 肯尼亚Kenya （1）, 利比里亚Liberia （3）, 刚果金Congo, DRC （1）, 喀麦隆Cameroon （2）, 塞拉利昂Sierra Leone （1）
K13/Pfmdr1	K13/86位点 K13/Locus 86	5	利比里亚Liberia （1）, 几内亚Guinea （1）,尼日利亚Nigeria （1）, 赤道几内亚Equatorial Guinea （2）
	K13/86/1246位点 K13/Locus 86/1246	1	利比里亚Liberia （1）

Table 2

Table 3

References 24

[1]	World Health Organization.World Malaria Report 2016[R]. Geneva: WHO, 2016.
[2]	Mita T, Tanabe K, Kita K.Spread and evolution of Plasmodium falciparum drug resistance[J]. Parasitol Int, 2009, 58(3): 201-209.
[3]	Wang Z, Shrestha S, Li X, et al. Prevalence of K13-propeller polymorphisms in Plasmodium falciparum from China-Myanmar border in 2007-2012[J]. Malar J, 2015, 14: 168.
[4]	官亚宜, 汤林华, 胡铃, 等. 海南恶性疟原虫分离株Pfcrt和Pfmdr1基因点突变的研究[J]. 中国寄生虫学与寄生虫病杂志, 2005, 23(3): 135-139.
[5]	Alareqi LM, Mahdy MA, Lau YL, et al. Molecular markers associated with resistance to commonly used antimalarial drugs among Plasmodium falciparum isolates from a malaria-endemic area in Taiz governorate-Yemen during the transmission season[J]. Acta Trop, 2016, 162: 174-179.
[6]	Ariey F, Witkowski B, Amaratunga C, et al. A molecular marker of artemisinin-resistant Plasmodium falciparum malaria[J]. Nature, 2013, 505(7481): 50-55.
[7]	Takala-Harrison S, Jacob CG, Arze C, et al. Independent emergence of artemisinin resistance mutations among Plasmodium falciparum in Southeast Asia[J]. J Infect Dis, 2015, 211(5): 670-679.
[8]	White NJ.Malaria: a molecular marker of artemisinin resistance[J]. Lancet, 2014, 383(9927): 1439-1440.
[9]	周瑞敏, 王轶楠, 钱丹, 等. 2015年河南省输入性恶性疟原虫Pfcrt基因的多态性分析[J]. 中国寄生虫学与寄生虫病杂志, 2016, 34(5): 399-404.
[10]	Lim P, Alker AP, Khim N, et al. Pfmdr1 copy number and arteminisin derivatives combination therapy failure in falciparum malaria in Cambodia[J]. Malar J, 2009, 8: 11.
[11]	Ranford-Cartwright LC, Johnston KL, Abdel-Muhsin AM, et al. Critical comparison of molecular genotyping methods for detection of drug-resistant Plasmodium falciparum[J]. Trans R Soc Trop Med Hyg, 2002, 96(5): 568-572.
[12]	Taylor SM, Parobek CM, DeConti DK, et al. Absence of putative artemisinin resistance mutations among Plasmodium falciparum in Sub-Saharan Africa: a molecular epidemiologic study[J]. J Infect Dis, 2015, 211(5): 680-688.
[13]	钱丹, 张红卫, 周瑞敏, 等. 河南省2009-2013年疟疾流行特征及趋势分析[J]. 中国热带医学, 2015, 15(1): 64-66.
[14]	杨成运, 鲁德领, 周瑞敏, 等. 河南省2013年疟疾疫情分析[J]. 中国寄生虫学与寄生虫病杂志, 2014, 32(5): 370-372.
[15]	贾西帅, 周水茂, 徐明星, 等. 武汉市输入性恶性疟原虫多药抗性基因1相关位点突变分析[J]. 中国寄生虫学与寄生虫病杂志, 2016, 34(6): 489-492.
[16]	徐超, 魏庆宽, 李瑾, 等. 输入性恶性疟原虫耐药相关基因Pfcrt和Pfmdr1单倍型及突变分析[J]. 中国人兽共患病学报, 2016, 32(12): 1051-1057.
[17]	Lobo E, de Sousa B, Rosa S, et al. Prevalence of Pfmdr1 alleles associated with artemether-lumefantrine tolerance/resistance in Maputo before and after the implementation of artemisinin-based combination therapy[J]. Malar J, 2014, 13: 300.
[18]	Naomi WL, Franklin K, Sheila AO, et al. In vitro and molecular surveillance for antimalarial drug resistance in Plasmodium falciparum parasites in Western Kenya reveals sustained artemisinin sensitivity and increased chloroquine sensitivity[J]. Antimicrob Agents Chemother, 2015, 59(12): 7540-7547.
[19]	Noedl H, Se Y, Schaecher K, et al. Evidence of artemisinin-resistant malaria in western Cambodia[J]. N Engl J Med, 2008, 359(24): 2619-2620.
[20]	Dondorp AM, Nosten F, Yi P, et al. Artemisinin resistance in Plasmodium falciparum malaria[J]. N Engl J Med, 2009, 361(5): 455-467.
[21]	Nyunt MH, Hlaing T, Oo HW, et al. Molecular assessment of artemisinin resistance markers, polymorphisms in the K13 propeller, and a multidrug-resistance gene in the eastern and western border areas of Myanmar[J]. Clin Infect Dis, 2015, 60(8): 1208-1215.
[22]	Win AA, Imwong M, Kyaw MP, et al. Erratum to: K13 mutations and Pfmdr1 copy number variation in Plasmodium falciparum malaria in Myanmar[J]. Malar J, 2016, 15(1): 297.
[23]	Feng J, Li J, Yan H, et al. Evaluation of antimalarial resistance marker polymorphism in returned migrant workers in China[J]. Antimicrob Agents Chemother, 2015, 59(1): 326-330.
[24]	Kamau E, Campino S, Amenga-Etego L, et al. K13-propeller polymorphisms in Plasmodium falciparum parasites from sub-Saharan Africa[J]. J Infect Dis, 2015, 211(8): 1352-1355.

基因 Gene	位点 Locus	引物 Primer	引物序列(5′→3′) Sequence (5′→3′)	片段长度/bp Fragment length/bp
Pfmdr1	86	P1	TTAAATGTTTACCTGCACAACATAGAA AATT	520
		P2	CTCCACAATAACTTGCAACAGTTCTTA
		N1	TGTATGTGCTGTATTATCAGGA
		N2	CTCTTCTATAATGGACATGGTA
	1246	P3	GGGGGATGACAAATTTTCAAGATTA	203
		P4	GGGGGACTAACAAGTTTAACATCTT
		N3	AATGTAAATGAATTTTCAAACC
		N4	CATCTTCTCTTCCAAATTTGATA
K13		P5	GCCTTGTTGAAAGAAGCAGAA	751
		P6	CGCCATTTTCTCCTCCTGTA
		N6	GTGGCAGCTCCAAAATTCAT
