Morphological observation and phylogenetic analysis for adult Histiostoma feroniarum

doi:10.12140/j.issn.1000-7423.2023.03.013

Abstract

Abstract:

Objective To observe the morphological characteristics of adult Histiostoma feroniarum under the electron microscope, and to study the genetic relationship between this species and other mite species of Acaridae. Methods The adult stage of H. feroniarum was isolated from the culture, and its external morphological features were observed using scanning electron microscopy (SEM), followed by extracting the mite DNA, for amplifying the cytochrome oxidase subunit 1 (cox1) and internal transcribed spacer (ITS) by PCR. The ITS and cox1 gene was sequenced and compared with the other 8 Acaridae species in GenBank. The phylogenetic tree was constructed by the maximum likelihood method. Results Under the electron microscope, the ventral epidermal protrusions of the mites were more developed. The epidermal protrusions of foot I healed into the chest plate, and the epidermal protrusions of foot Ⅱ extended to the centre and were not connected. There were 2 pairs of chitinous rings on the ventral surface, and the male adults were located between the Ⅱ-Ⅳ basal ganglia. The first pair of chitin rings of the female mite was located between the foot Ⅱ and Ⅲ, and the last pair of chitin rings were located at the level of the foot Ⅳ basal ganglia. Compared with the light microscope, the structures of male reproductive folds, leaflets and penis were clearer under the electron microscope. The cox1 and ITS sequences were obtained by PCR amplification, which was 539 bp and 1 633 bp. The ITS sequence similarity comparison results showed that the sequence similarity between H. feroniarum and Blomia tropicalis (GenBank accession no. KC215362) was the highest, which was at 90.41%, and the sequence similarity with other Acaridae species was 83.33%-89.73%. The cox1 sequence alignment showed that the highest sequence similarity was 83.55% between H. feroniarum and Lepidoglyphus destructor (GenBank accession no. MT075728), and the sequence similarity with other Acaridae species ranged from 79.78%-82.12%. The phylogenetic tree constructed based on ITS and cox1 sequences has differences in topological structure. showing that H. feroniarum is a single branch, but not at the same branch of other Acaridae species, which is likely consistent with morphological classification. The phylogenetic analysis based on ITS showed that H. feroniarum and Rhizoglyphus robini were clustered as a branch, which differs from morphological classification. Conclusion The morphological structure of male and female H. feroniarum could be clearly observed by scanning electron microscopy. Phylogenetic analysis of cox1 sequence reveals relatively distant genetic relationship seen between the H. feroniarum and other acaroid mites.

Key words: Histiostoma feroniarum, Scanning electron microscopy, External morphology, Phylogeny

CLC Number:

R384.429

TANG Feifan, JIANG Feng, WANG Meiqing, WANG Lan, CAO Jiacheng, XIA Yuting, WANG Jingxuan, TANG Liqing, ZHAN Xiaodong. Morphological observation and phylogenetic analysis for adult Histiostoma feroniarum[J]. CHINESE JOURNAL OF PARASITOLOGY AND PARASITIC DISEASES, 2023, 41(3): 344-348.

Figures/Tables 4

Table 1

Fig. 1

Fig. 2

Fig. 3

References 18

[1]	Xu W, Zhu ZW, Sun ET, et al. Identification of morphologica and molecular charateristis of Histiostoma feroniarum hypopus[J]. J Youjiang Med Univ Nat, 2019, 41(3): 246-249. (in Chinese)
	(许薇, 朱志伟, 孙恩涛, 等. 速生薄口螨休眠体的形态和分子特征鉴定[J]. 右江民族医学院学报, 2019, 41(3): 246-249.)
[2]	Li CP, Shen ZP. Introduction to acaroid mites in China[M]. Beijing: Science Press, 2016: 454-462. (in Chinese)
	(李朝品, 沈兆鹏. 中国粉螨概论[M]. 北京: 科学出版社, 2016: 454-462.)
[3]	Lan QX, Lu ZH, Fan QH. Research progress of mite species on mushroom[J]. Fujian J Agric Sci, 2012, 27(1): 104-108. (in Chinese)
	(兰清秀, 卢政辉, 范青海. 食用菌螨种类研究进展[J]. 福建农业学报, 2012, 27(1): 104-108.)
[4]	Jiang JJ, Li CP. Mites of edible fungi in China and their control methods[J]. J Trop Dis Parasitol, 2005, 3(4): 250-252. (in Chinese)
	(江佳佳, 李朝品. 我国食用菌螨类及其防治方法[J]. 热带病与寄生虫学, 2005, 3(4): 250-252.)
[5]	Zhao XP, Liu XG. Mass culture of Histiostoma laboratorium and their hypopi induction[J]. Chin J Zool, 2011, 46(4): 42-46. (in Chinese)
	(赵晓平, 刘晓光. 实验室薄口螨的大量培养及休眠体的诱导[J]. 动物学杂志, 2011, 46(4): 42-46.)
[6]	Hong Y, Tao N, Zhan XD, et al. Morphologic observation on Histiostoma feroniarum in Allium cepa[J]. Chin J Schisto Control, 2016, 28(3): 301-303. (in Chinese)
	(洪勇, 陶宁, 湛孝东, 等. 洋葱害螨速生薄口螨的形态观察[J]. 中国血吸虫病防治杂志, 2016, 28(3): 301-303.)
[7]	Chai Q, Guo JJ, Tao N, et al. Investigation and morphological observation of Histiostoma feroniarum breeding in Chinese herbal medicine Rhizoma Zingiberis[J]. Chin J Schisto Control, 2017, 29(6): 776-777, 818. (in Chinese)
	(柴强, 郭娇娇, 陶宁, 等. 中药材生姜孳生速生薄口螨的情况调查及形态观察[J]. 中国血吸虫病防治杂志, 2017, 29(6): 776-777, 818.)
[8]	Duan BB, Zhan XD, Song HY, et al. Morphology observation of Histiostoma feroniarum hypopus[J]. Chin J Schisto Control, 2015, 27(04): 414-415. (in Chinese)
	(段彬彬, 湛孝东, 宋红玉, 等. 食用菌速生薄口螨休眠体光镜下形态观察[J]. 中国血吸虫病防治杂志, 2015, 27(4): 414-415.)
[9]	Lu YH. The research on Histrostoma feroniarumin mushroom the new record in Jiangxi[J]. J Yichun Univ (Nat Sci), 2002, 24(4): 57-59. (in Chinese)
	(陆云华. 食用菌害螨江西新纪录: 速生薄口螨的研究[J]. 宜春学院学报(自然科学), 2002, 24(4): 57-59.)
[10]	Xu W, Zhu ZW, Luo X, et al. Morphological and molecular characterization of mite Tyrophagus putrescentiae[J]. Chin J Parasitol Parasit Dis, 2020, 38(1): 95-101. (in Chinese)
	(许薇, 朱志伟, 罗欣, 等. 腐食酪螨的形态和分子特征鉴定[J]. 中国寄生虫学与寄生虫病杂志, 2020, 38(1): 95-101.)
[11]	Hu WH. Edible fungus mite in seed cultivation and prevention[J]. Southwest Hortic, 2002(3): 26. (in Chinese)
	(胡文华. 食用菌制种栽培中菌螨的发生与防治[J]. 西南园艺, 2002(3): 26.)
[12]	Liu YJ, Yu DJ, Zhu P. Histiostoma feronirum Dufour and ginseng necrosis[J]. Chin Wild Plant Resour, 1993, 12(2): 17-22. (in Chinese)
	(刘雅杰, 于德江, 朱平. 速生薄口螨Histiostoma feronirum Dufour与人参坏死病[J]. 中国野生植物资源, 1993, 12(2): 17-22.)
[13]	Liu T, Jin DC. Observations on the external morphology of different developmental stages of Chortoglyphus arcuatus (Sarcoptiformes ∶ Chotoglyphidae)[J]. Acta Entomol Sin, 2014, 57(6): 737-744. (in Chinese)
	(刘婷, 金道超. 拱殖嗜渣螨各发育阶段的体表形态观察[J]. 昆虫学报, 2014, 57(6): 737-744.)
[14]	Gu XB, Zhang XQ, Yang GY, et al. Sequence analysis and phylogenetic relationships of 11 mite isolates based on ITS-2 gene[J]. Acta Vet Zootechnica Sin, 2009, 40(2): 235-242. (in Chinese)
	(古小彬, 张晓谦, 杨光友, 等. 11株螨虫分离株的ITS-2序列分析与系统关系研究[J]. 畜牧兽医学报, 2009, 40(2): 235-242.)
[15]	Zou ZW, Chen F, Xia B, et al. Sequence analysis of ITS gene in several Amblyseiinae (Acari ∶ Phytoseiidae)[J]. Sci Agric Sin, 2011, 44(23): 4945-4951. (in Chinese)
	(邹志文, 陈芬, 夏斌, 等. 几种钝绥螨ITS基因片段的序列分析[J]. 中国农业科学, 2011, 44(23): 4945-4951.)
[16]	Yang SY, Zhou XL, Song LW, et al. Analysis of genetic differentiation among different geographic populations of Tetranychus truncatus (Acari ∶ Tetranychidae) in Gansu Province, northwestern China based on mtDNA COI gene[J]. Acta Entomol Sin, 2017, 60(9): 1083-1092. (in Chinese)
	(杨顺义, 周兴隆, 宋丽雯, 等. 基于mtDNA COI基因的甘肃截形叶螨不同地理种群遗传分化分析[J]. 昆虫学报, 2017, 60(9): 1083-1092.)
[17]	Jia XY, Yang GY, Guo XB, et al. Nucleotide variation in rDNA ITS-2 differentiates Psoroptes isolates from rabbits and buffalo[J]. Acta Entomol Sin, 2008(05): 545-550. (in Chinese)
	(贾小勇, 杨光友, 古小彬, 等. 兔痒螨和水牛痒螨第二转录间隔区(ITS-2)基因序列分析[J]. 昆虫学报, 2008, 51(5): 545-550.)
[18]	Chen S, Zheng YW. Blomia tropicalis allergens and clinical investigations[J]. Chin J Allergy Clin Immunol, 2012, 6(2): 158-162. (in Chinese)
	(陈实, 郑轶武. 热带无爪螨致敏蛋白组分及其临床研究[J]. 中华临床免疫和变态反应杂志, 2012, 6(2): 158-162.)

科 Family	属 Genera	种 Species	GenBank登录号 GenBank accession no.
科 Family	属 Genera	种 Species	ITS	cox1
薄口螨科 Histiostomidae	薄口螨属 Histiostoma	速生薄口螨 Histiostoma feroniarum	OP113839	-
粉螨科 Acaridae	食酪螨属 Tyrophagus	腐食酪螨 Tyrophagus putrescentiae	MN545441	MK3937921
粉螨科 Acaridae	食酪螨属 Tyrophagus	长食酪螨 Tyrophagus longior	KC215312	NC_028725
粉螨科 Acaridae	食粉螨属 Aleuroglyphus	椭圆食粉螨 Aleuroglyphus ovatus	KJ841895	NC_023778
粉螨科 Acaridae	根螨属 Rhizoglyphus	罗宾根螨 Rhizoglyphus robini	DQ372568	NC_038058
麦食螨科 Pyroglyphidae	尘螨属 Dermatophagoides	粉尘螨 Dermatophagoides farinae	KC215332	GQ465336
麦食螨科 Pyroglyphidae	尘螨属 Dermatophagoides	屋尘螨 Dermatophagoides pteronyssinus	MK589428	EU884425
食甜螨科 Glycyphagidae	无爪螨属 Blomia	热带无爪螨 Blomia tropicalis	KC215362	NC_062515
食甜螨科 Glycyphagidae	嗜鳞螨属 Lepidoglyphus	害嗜鳞螨 Lepidoglyphus destructor	KC215381	MT075728
叶螨科 Tetranychidae	叶螨属 Tetranychus	二斑叶螨 Tetranychus urticae	HM565890	EU345430
