刚地弓形虫sub3基因敲除株的构建及体外表型分析

doi:10.12140/j.issn.1000-7423.2025.03.003

中国寄生虫学与寄生虫病杂志 ›› 2025, Vol. 43 ›› Issue (3): 324-328.doi: 10.12140/j.issn.1000-7423.2025.03.003

刚地弓形虫sub3基因敲除株的构建及体外表型分析

王龙江()(), 吴燕, 李瑾, 谢金晶, 张欣, 孙慧^*()()

山东省寄生虫病防治研究所，山东第一医科大学（山东省医学科学院），山东济宁 272033

收稿日期:2024-11-01 修回日期:2025-03-17 出版日期:2025-06-30 发布日期:2025-06-25
通讯作者: *孙慧（ORCID：0009-0002-3967-6393），女，博士，副研究员，从事寄生虫病防治。E-mail: sunhui123aq@126.com
作者简介:王龙江（ORCID：0000-0003-0439-1945），男，硕士，助理研究员，从事寄生虫病防治研究。E-mail: ljwang880108@163.com
基金资助:
山东省自然科学基金(ZR2022MH271);山东省医药卫生科技项目(202301011242);山东省医药卫生科技项目(202101050153)

Generation of Toxoplasma gondii sub3 gene knockout strain and its in-vitro phenotypes

WANG Longjiang()(), WU Yan, LI Jin, XIE Jinjing, ZHANG Xin, SUN Hui^*()()

Shandong Institute of Parasitic Diseases, Shandong First Medical University (Shandong Academy of Medical Sciences), Jining 272033, Shandong, China

Received:2024-11-01 Revised:2025-03-17 Online:2025-06-30 Published:2025-06-25
Contact: *E-mail: sunhui123aq@126.com
Supported by:
Natural Science Foundation of Shandong Province(ZR2022MH271);Shandong Provincial Medical and Health Science and Technology Projects(202301011242);Shandong Provincial Medical and Health Science and Technology Projects(202101050153)

摘要/Abstract

摘要：

目的利用规律间隔成簇短回文重复序列关联蛋白9（CRISPR/Cas9）技术构建刚地弓形虫（Toxoplasma gondii）类枯草杆菌蛋白酶基因sub3敲除株并进行体外表型分析，探究TgSUB3对弓形虫黏附、入侵和生长繁殖的作用。方法利用定点突变方法将pSAG1::CAS9-U6::sgUPRT中的sgUPRT突变为Tgsub3的单向导RNA（sgRNA），构建sub3基因敲除质粒pSAG1::CAS9-U6::sgSUB3。PCR扩增带有sub3上下游40 bp同源臂的二氢叶酸还原酶抗性供体片段，将质粒和供体片段通过电转化的方式导入弓形虫RH∆ku80速殖子，经过乙胺嘧啶抗性选择和单克隆筛选，PCR鉴定敲除株RH∆ku80∆sub3（∆sub3）。鉴定正确的敲除株∆sub3进行噬斑试验、入侵试验和增殖试验，分析其体外表型，以RH∆ku80为对照，使用软件 GraphPad Prism 9进行统计学分析。结果经PCR鉴定，在∆sub3中扩增到的条带大小符合预期，∆sub3敲除株构建成功。噬斑试验结果显示，RH∆ku80和∆sub3形成的噬斑面积分别为（60.42 ± 23.20）任意单位和（2.21 ± 1.89）任意单位，二者差异有统计学意义（t = 17.79，P < 0.01）；入侵实验结果显示，RH∆ku80和∆sub3的入侵效率分别为（37.94 ± 18.18）%和（22.97 ± 15.36）%，差异无统计学意义（t = 0.89，P > 0.05）。增殖试验结果显示，RH∆ku80和∆sub3纳虫泡中含有8个及以上速殖子的纳虫泡数量分别为 (56.33 ± 8.58）% 和 (39.67 ± 11.84）%；含有4个及以下速殖子的纳虫泡数量分别为（43.67 ± 8.58）%和（60.33 ± 11.84）%，与 RH∆ku80 虫株相比，纳虫泡内速殖子个数显著减少（F = 17.93，P < 0.01）。结论成功构建弓形虫∆sub3敲除株，TgSUB3的缺失影响弓形虫速殖子的生长繁殖。

关键词: 刚地弓形虫, 类枯草杆菌蛋白酶3, CRISPR/Cas9, 表型分析

Abstract:

Objective To generate the Toxoplasma gondii sub3 (Tgsub3) gene knockout strain using the clustered regularly interspaced short palindromic repeats (CRISPR)/CRISPR-associated protein 9 (Cas9) system, investigate the in-vitro phenotypes of the Tgsub3 gene knockout strain, and examine the effect of Tgsub3 gene on adhesion, invasion and proliferation of T. gondii. Methods SgUPRT on the pSAG1::CAS9U6::SgUPRT plasmid was mutated to single guide RNA (sgRNA) using site mutation, and the pSAG1::CAS9-U6::sgSUB3 plasmid with the sub3 gene knockout was generated. The DHFR resistant donor fragments containing 40 bp upstream and downstream homology arms of the sub3 gene were amplified, and the sub3 gene knockout plasmid and donor fragments were co-transfected into T. gondii by electroporation. Following resistance selection by pyrimethamine and monoclonal screening, the sub3 gene knockout strain RH∆ku80∆sub3 (∆sub3) was identified using PCR assay. The in-vitro phenotypes of the ∆sub3 strain were analyzed with plaque, invasion, and proliferation assays. Using RH∆ku80 strain as a control, all statistical analyses were conducted using the software GraphPad Prism 9. Results PCR assay identified bands with expected sizes in the ∆sub3 strain, indicating successful generation of the ∆sub3 strain. Plaque assay showed that the sizes of plaques formed by RH∆ku80 and ∆sub3 strains were (60.42 ± 23.20) au and (2.21 ± 1.89) arbitrary unit, respectively (t = 17.79, P < 0.01), and invasion assay showed that the invasion efficiencies of RH∆ku80 and ∆sub3 strains were (37.94 ± 18.18) % and (22.97 ± 15.36) %, respectively (t = 0.89, P > 0.05). Proliferation assay showed that the proportions of parasitophorous vacuoles containing 8 and more tachyzoites of RH∆ku80 and ∆sub3 strainswere (56.33 ± 8.58) % and (39.67 ± 11.84) %, respectively, and the proportions of parasitophorous vacuoles containing 4 and fewer tachyzoites of RH∆ku80 and ∆sub3 strains were (43.67 ± 8.58) % and (60.33 ± 11.84) %, respectively. Compared with control strain, the number of tachyzoites within the parasitophorous vacuole was significantly decreased (F = 17.93, P < 0.01). Conclusion The ∆sub3 gene knockout strain is successfully generatedand absence of the Tgsub3 gene affects the growth and reproduction of T. gondii tachyzoites.

Key words: Toxoplasma gondii, Subtilisin-like protease 3, CRISPR/Cas9, Phenotype analysis

中图分类号:

R382.5

王龙江, 吴燕, 李瑾, 谢金晶, 张欣, 孙慧. 刚地弓形虫sub3基因敲除株的构建及体外表型分析[J]. 中国寄生虫学与寄生虫病杂志, 2025, 43(3): 324-328.

WANG Longjiang, WU Yan, LI Jin, XIE Jinjing, ZHANG Xin, SUN Hui. Generation of Toxoplasma gondii sub3 gene knockout strain and its in-vitro phenotypes[J]. Chinese Journal of Parasitology and Parasitic Diseases, 2025, 43(3): 324-328.

图/表 5

表1

图1

图2

图3

图4

参考文献 24

[1]	Smith NC, Goulart C, Hayward JA, et al. Control of human toxoplasmosis[J]. Int J Parasitol, 2021, 51(2/3): 95-121.
[2]	Montoya JG, Liesenfeld O. Toxoplasmosis[J]. Lancet, 2004, 363(9425): 1965-1976.
[3]	王杰, 温红阳, 陈滢, 等. 刚地弓形虫巨噬细胞迁移抑制因子基因敲除虫株的构建与鉴定[J]. 中国寄生虫学与寄生虫病杂志, 2022, 40(3): 349-354.
	Wang J, Wen HY, Chen Y, et al. Construction and identification of macrophage migration inhibitory factor gene knockout strain of Toxoplasma gondii[J]. Chin J Parasitol Parasit Dis, 2022, 40(3): 349-354. (in Chinese)
[4]	Saadatnia G, Golkar M. A review on human toxoplasmosis[J]. Scand J Infect Dis, 2012, 44(11): 805-814.
[5]	Buxton D, Innes EA. A commercial vaccine for ovine toxoplasmosis[J]. Parasitology, 1995, 110 Suppl: S11-S16.
[6]	李仕毓, 李静, 陆绍红, 等. 宿主细胞自主免疫抗弓形虫的研究进展[J]. 中国寄生虫学与寄生虫病杂志, 2024, 42 (5): 653-658, 663.
	LI SY, Li J, Lu SH, et al. Research advances on host cell autonomous immunity against Toxoplasma gondii[J]. Chin J Parasitol Parasit Dis, 2024, 42(5): 653-658, 663. (in Chinese)
[7]	Luo C, Wang QQ, Guo RH, et al. A novel pseudorabies virus vaccine developed using HDR-CRISPR/Cas9 induces strong humoral and cellular immune response in mice[J]. Virus Res, 2022, 322: 198937.
[8]	Apinda N, Yao YX, Zhang YY, et al. CRISPR/Cas9 editing of duck enteritis virus genome for the construction of a recombinant vaccine vector expressing ompH gene of Pasteurella multocida in two novel insertion sites[J]. Vaccines (Basel), 2022, 10(5): 686.
[9]	吴燕, 张欣, 李瑾, 等. 基于CRISPR/Cas9技术的弓形虫病疫苗研究进展[J]. 中国血吸虫病防治杂志, 2024, 36(5): 542-547.
	Wu Y, Zhang X, Li J, et al. Progress of researches on toxoplasmosis vaccines based on the CRISPR/Cas9 technology[J]. Chin J Schisto Control, 2024, 36(5): 542-547. (in Chinese)
[10]	Nyonda MA, Hammoudi PM, Ye S, et al. Toxoplasma gondii GRA60 is an effector protein that modulates host cell autonomous immunity and contributes to virulence[J]. Cell Microbiol, 2021, 23(2): e13278.
[11]	Mamaghani AJ, Fathollahi A, Arab-Mazar Z, et al. Toxoplasma gondii vaccine candidates: A concise review[J]. Ir J Med Sci, 2023, 192(1): 231-261.
[12]	牛美容, 李法财, 谢世臣, 等. 弓形虫Tgcsp2基因敲除株的表型和毒力[J]. 中国兽医学报, 2020, 40(1): 140-146.
	Niu MY, Li FC, Xie SC, et al. Phenotypes and virulence of Tgcsp2 gene knockout Toxoplasma gondii[J]. Chin J Vet Sci, 2020, 40(1): 140-146. (in Chinese)
[13]	Zhang ZW, Li TT, Wang JL, et al. Functional characterization of two thioredoxin proteins of Toxoplasma gondii using the CRISPR-Cas9 system[J]. Front Vet Sci, 2021, 7: 614759.
[14]	Dubey JP. History of the discovery of the life cycle of Toxoplasma gondii[J]. Int J Parasitol, 2009, 39(8): 877-882.
[15]	Kim K. Role of proteases in host cell invasion by Toxoplasma gondii and other Apicomplexa[J]. Acta Trop, 2004, 91(1): 69-81.
[16]	Withers-Martinez C, Suarez C, Fulle S, et al. Plasmodium subtilisin-like protease 1(SUB1): insights into the active-site structure, specificity and function of a pan-malaria drug target[J]. Int J Parasitol, 2012, 42(6): 597-612.
[17]	Lagal V, Binder EM, Huynh MH, et al. Toxoplasma gondii protease TgSUB1 is required for cell surface processing of micronemal adhesive complexes and efficient adhesion of tachyzoites[J]. Cell Microbiol, 2010, 12(12): 1792-1808.
[18]	Binder EM, Lagal V, Kim K. The prodomain of Toxoplasma gondii GPI-anchored subtilase TgSUB1 mediates its targeting to micronemes[J]. Traffic, 2008, 9(9): 1485-1496.
[19]	Miller SA, Thathy V, Ajioka JW, et al. TgSUB2 is a Toxoplasma gondii rhoptry organelle processing proteinase[J]. Mol Microbiol, 2003, 49(4): 883-894.
[20]	邓敏儿, 李娜, 郭亚琼, 等. CRISPR/Cas9系统在寄生原虫基因编辑中的应用[J]. 畜牧兽医学报, 2023, 54(1): 69-79.
	Deng ME, Li N, Guo YQ, et al. Application of CRISPR/Cas9 system on gene editing of parasitic protozoa[J]. 2023, 54(1): 69-79.
[21]	闫书宁, 杨硕, 杨汉银, 等. CRISPR/Cas系统在寄生虫基因编辑与核酸检测中的应用进展[J]. 中国血吸虫病防治杂志, 2024, 36(3): 314-332.
	Yan SN, Yang S, Yang HY, et al. Application of the CRISPR/Cas system in gene editing and nucleic acid detection of parasitic diseases: A review[J]. Chin J Schisto Control, 2024, 36(3): 314-332.
[22]	You H, Gordon CA, MacGregor SR, et al. Potential of the CRISPR-Cas system for improved parasite diagnosis: CRISPR-Cas mediated diagnosis in parasitic infections[J]. Bioessays, 2022, 44(4): 2100286.
[23]	Gallagher DN, Haber JE. Repair of a site-specific DNA cleavage: Old-school lessons for Cas9-mediated gene editing[J]. ACS Chem Biol, 2018, 13(2): 397-405.
[24]	Shen B, Brown KM, Lee TD, et al. Efficient gene disruption in diverse strains of Toxoplasma gondii using CRISPR/CAS9[J]. mBio, 2014, 5(3): e01114-14.

引物名称Primer name	序列（5′→3′）Sequence (5′→3′)
sgRNA-F	GTGCTGAGTTACTCTCTCAA
sgRNA-R	AACTTGACATCCCCATTTAC
sub3-40nt-F	CAGTGGCTTGAACCATATCTACGCTCTGAGGATTCC-ACACCTAGCATGTCATTCGATT
sub3-40nt-R	TTTTTTCTGGTGGTACTTTGTGCCTGGGACCGCTTCC-AATCATCCTGCAAGTGCATAG
sub3-PCR1-F	ACCATTTCGTCTTCTAGCTCGA
sub3-PCR1-R	CGTTGAATGTGCGGGGGAAC
sub3-PCR2-F	TTATCGAAGAAAAGGGATGA
sub3-PCR2-R	GTAGTGGGATGGCTATCACTG
sub3-PCR3-F	ACCATTTCGTCTTCTAGCTCGA
sub3-PCR3-R	AATTGGTCGAGGACAAGCGGA
