Analysis of miRNA expression in Echinococcus granulosus protoscoleces isolated from sheep liver and lung

doi:10.12140/j.issn.1000-7423.2019.02.004

Abstract

Abstract:

Objective The expression of microRNA (miRNA) in Echinococcus granulosus protoscoleces isolated from liver (hepatic protoscoleces, HPSC) and lung (lung protoscoleces, LPSC) of infected sheep was analyzed, and the specific miRNAs expressed in E. granulosus were identified by screening available databases in order to provide E. granulosus miRNA information for further study. Methods The fresh sheep livers and lungs with hydatid cysts were collected from a slaughter house near the suburb of Xining City. The hydatid cysts were extracted, filtered and precipitated to obtain pure protoscoleces of E. granulosus. The total RNA was extracted from cysts using TRIzol, and the HPSC and LPSC small RNA (sRNA) libraries were constructed. The deep sequencing was performed on these libraries using high-throughput sequencing technology. The obtained sequences were used to compare with databases including miRBase, Pre-miRNA database, RFam and Repbase to obtain E. granulosus specific miRNA information. The secondary structure of E. granulosus miRNA was predicted using mfold software. The differences in miRNA expression between HPSC and LPSC were compared. Results The E. granulosus HPSC and LPSC sRNA libraries were successfully constructed and total 10 182 508 and 11 133 735 effective sequences, respectively, were obtained. Most of the sequences were 18-22 nucleotide (nt) long, of which 22 nt had the highest frequency accounting for 20.9% (2 128 728/10 182 508) for HPSC and 24.6%(2 737 570/11 133 735) for LPSC, followed by 19 nt (14.0%, 1 429 846/10 182 508; 18.5%, 1 880 607/10 182 508) and 21 nt (16.9%, 1 875 698/11 133 735; 16.9%, 1 885 560/11 133 735), respectively. Except for 87 and 79 known miRNA, total 341 and 339 new miRNAs were identified in the constructed E. granulosus HPSC and LPSC sRNA libraries, respectively. Among them 58 for HPSC and 62 for LPSC were conserved with sequences of Schistosoma japonicum, S. mansoni, Platyhelminthes and Gyrodactylus. In the known miRNA of E. granulosus, 8 miRNA including egr-miR-36a-3p, egr-miR-36b-3p, egr-miR-10229a-5p, egr-miR-10233-5p, egr-miR-10240-3p, egr-miR-10243-5p, egr-mir-10252-5p and egr-mir-10287-5p were specifically expressed in the HPSC library, and the remaining miRNA were expressed in both HPSC and LPSC sRNA libraries at the same level. Among other helminth-conserved miRNA, 50 were co-expressed in both HPSC and LPSC, 8 were specifically expressed in HPSC and 12 in LPSC. Among the new identified miRNA, 78 were specifically expressed in HPSC and 76 in LPSC. Of the 574 miRNA identified in two libraries, 392 miRNA were co-expressed in both libraries with following top 10 highest expression miRNAs: egr-miR-1-5p, egr-miR-2a-3p, egr-miR-2c-3p, egr-miR-2b-3p, egr-miR-7-5p, egr-let-7-5p, egr-miR-7b-5p, egr-miR-9-5p, egr-miR-9-3p, egr-miR-10a-5p. Compared with HPSC, 124 miRNAs were up-regulated by more than 2-fold and 30 miRNAs down-regulated by 0.5-fold in LPSC. Among the total miRNA identified in both libraries, 94 and 88 were specifically expressed in HPSC and LPSC, respectively. Conclusion This study identified the specific expression of miRNA in HPSC and LPSC.

Key words: Echinococcus granulosus, miRNA, Expression analysis

CLC Number:

R383.33

Shi-qiang FU, Hai-ning FAN, Hai-jiu WANG, Ying ZHOU, De-ping CAO, Yan-fei LI, Zhi-xin WANG, Li REN. Analysis of miRNA expression in Echinococcus granulosus protoscoleces isolated from sheep liver and lung[J]. CHINESE JOURNAL OF PARASITOLOGY AND PARASITIC DISEASES, 2019, 37(2): 137-143.

Figures/Tables 8

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Table 1

Fig. 5

Table 2

Table 3

References 17

[1]	Bartel DP.MicroRNAs: target recognition and regulatory functions[J]. Cell, 2009, 136(2): 215-233.
[2]	Tüfekci KU, Meuwissen RL, Genç S.The role of microRNAs in biological processes[J]. Methods Mol Biol, 2014, 1107: 15-31.
[3]	Bartel DP.MicroRNAs: genomics, biogenesis, mechanism, and function[J]. Cell, 2004, 116(2): 281-297.
[4]	Pasquinelli AE, Reinhart BJ, Slack F, et al. Conservation of the sequence and temporal expression of let-7 heterochronic regulatory RNA[J]. Nature, 2000, 408(6808): 86-89.
[5]	Jia B, Chang Z, Wei X, et al. Plasma microRNAs are promising novel biomarkers for the early detection of Toxoplasma gondii infection[J]. Parasit Vectors, 2014, 7: 433.
[6]	Huang J, Hao P, Chen H, et al. Genome-wide identification of Schistosoma japonicum microRNAs using a deep-sequencing approach[J]. PLoS One, 2009, 4(12): e8206.
[7]	伍卫平, 王虎, 王谦, 等. 2012-2016年中国棘球蚴病抽样调查分析[J]. 中国寄生虫学与寄生虫病杂志, 2018, 36(1): 1-14.
[8]	何伟, 王谦, 黄燕, 等. 2007-2012年四川省包虫病流行区网络直报疫情分析[J]. 中国病原生物学杂志, 2014, 9(1): 68-70.
[9]	曹薇微. 囊型肝包虫囊周肝组织与正常肝组织差异基因与差异蛋白的初步筛选及研究[D]. 西宁: 青海大学, 2008.
[10]	Kumaratilake LM, Thompson RCA.A review of the taxonomy and speciation of the genus Echinococcus Rudolphi 1801[J]. Z Parasitenkd, 1982, 68(2): 121-146.
[11]	Rausch RL, Bernstein JJ.Echinococcus vogeli sp. n. (Cestoda: Taeniidae) from the bush dog, Speothos venaticus (Lund)[J]. Z Tropenmed Parasitol, 1972, 23(1): 25-34.
[12]	任梦迪, 宁玉烨, 黎明, 等. 细粒棘球蚴病患者外周血微小RNA的差异表达分析及其特异性诊断标志物的筛选[J]. 中国寄生虫学与寄生虫病杂志, 2017, 35(5): 423-428.
[13]	Bai Y, Zhang Z, Jin L, et al. Genome-wide sequencing of small RNAs reveals a tissue-specific loss of conserved microRNA families in Echinococcus granulosus[J]. BMC Genomics, 2014, 15: 736.
[14]	Fromm B, Trelis M, Hackenberg M, et al. The revised microRNA complement of Fasciola hepatica reveals a plethora of overlooked microRNAs and evidence for enrichment of immuno-regulatory microRNAs in extracellular vesicles[J]. Int J Parasitol, 2015, 45(11): 697-702.
[15]	Ovchinnikov VY, Afonnikov DA, Vasiliev GV, et al. Identification of microRNA genes in three opisthorchiids[J]. PLoS Negl Trop Dis, 2015, 9(4): e0003680.
[16]	张方, 胡子乔, 景炅婕, 等. 绵羊不同部位脂肪组织microRNA高通量测序及生物信息学分析[J]. 畜牧兽医学报, 2016, 47(6): 1093-1101.
[17]	Sun J, Li M, Li Z, et al. Identification and profiling of conserved and novel microRNAs from Chinese Qinchuan bovine longissimus thoracis[J]. BMC Genomics, 2013, 14: 42.

miRNA名称 miRNA name	相对表达量Relative expression level
miRNA名称 miRNA name	HPSC	LPSC
egr-miR-1-5p	4 749.9	7 137.9
egr-miR-2a-3p	6 293.2	3 235.5
egr-miR-2c-3p	11 388.6	7 617.0
egr-miR-2b-3p	14 499.0	8 344.5
egr-miR-7-5p	2 194.3	4 180.1
egr-let-7-5p	29 471.2	45 604.0
egr-miR-7b-5p	1 034.5	2 420.5
egr-miR-9-5p	5 854.9	8 052.8
egr-miR-9-3p	560.3	271.7
egr-miR-10a-5p	10 095.7	6 486.7
egr-miR-61-3p	2 920.6	2 265.7
egr-miR-71-5p	68 100.4	112 588.0
egr-miR-87-3p	302.5	519.4
egr-miR-96-5p	3 578.9	2 454.4
egr-miR-124b-3p	5 269.5	3 838.5
egr-miR-125-5p	20 687.7	14 484.1
egr-miR-184-3p	16 770.3	19 853.5
egr-miR-190-5p	681.9	1 620.3
egr-miR-219-5p	3 884.7	2 596.1
egr-miR-277a-3p	3 373.9	3 015.3
egr-miR-281-3p	3 787.8	2 752.1
egr-miR-745-3p	5 386.4	5 501.8
egr-miR-2162-3p	3 603.1	1 532.2
egr-miR-3479a-3p	2 825.3	1 730.9
egr-miR-4989-3p	14 009.5	8 662.5
sma-miR-1b-3p	1 961.5	3 262.4
gsa-miR-87-3p	6 331.6	12 628.4
sme-mir-749-p3	4.4	8.5
bmo-mir-6497-p5	1.7	5.6
lgi-miR-100	1.4	98.4
prd-let-7-5p	5.0	509.4

miRNA	差异倍数Fold change	上调/下调Up/down
prd-let-7-5p	101.4	上调Up
lgi-miR-100	71.8	上调Up
aga-miR-92a	46.3	上调Up
aae-miR-92a-3p	46.3	上调Up
tur-miR-92-3p	46.3	上调Up
PC-3p-34218_161	16.6	上调Up
PC-3p-95756_44	11.9	上调Up
PC-3p-48670_108	10.2	上调Up
PC-3p-52795_98	8.8	上调Up
PC-3p-125187_29	8.3	上调Up
PC-3p-70159_69	7.5	上调Up
PC-3p-71169_67	7.3	上调Up
PC-3p-68407_71	6.8	上调Up
PC-5p-102730_40	6.8	上调Up
PC-3p-90370_48	6.8	上调Up
PC-3p-97537_43	6.8	上调Up
PC-5p-68303_71	6.6	上调Up
PC-5p-29352_189	6.5	上调Up
PC-3p-22591_246	6.3	上调Up
PC-3p-126082_29	6.3	上调Up
PC-3p-27703_201	6.1	上调Up
PC-3p-47625_111	6.0	上调Up
PC-5p-105060_39	6.0	上调Up
PC-3p-37448_146	5.8	上调Up
PC-3p-22154_250	5.4	上调Up
PC-3p-56267_91	5.4	上调Up
PC-3p-56802_90	5.2	上调Up
PC-5p-63015_79	5.1	上调Up
egr-miR-8-3p	0.2	下调Down
egr-miR-96-3p	0.2	下调Down
PC-5p-49121_107	0.2	下调Down
