Echinococcus granulosus native antigen B regulating macrophage polarization through the STAT6/PPAR-γ signaling pathway in vitro

doi:10.12140/j.issn.1000-7423.2025.05.005

Abstract

Abstract:

Objective To investigate the regulatory effect of native antigen B (nAgB) from Echinococcus granulosus on the polarization of RAW264.7 macrophages in vitro and its potential involvement in the Signal Transducer and Activator of Transcription 6 (STAT6)/peroxisome proliferator-activated receptor-γ (PPAR-γ) signaling pathway. Methods nAgB was extracted and purified under sterile conditions. RAW264.7 cells were treated with nAgB at concentrations of 0, 1, 4, 16, and 64 μg/ml. Cell viability was assessed at 0, 6, 12, 24, and 48 hours using the CCK8 assay, and cell proliferation was evaluated at 24 hours via 5-ethynyl-2-deoxyuridine (EdU) staining. Cells were divided into 6 groups: control group, M1-polarized group, M2-polarized group, nAgB group, nAgB-treated M1-polarized group, and nAgB-treated M2-polarized group. The nAgB, nAgB-treated M1-polarized, and nAgB-treated M2-polarized groups were treated with 1 μg/ml nAgB. After 1 hour of intervention, the M1-polarized and nAgB-treated M1-polarized groups were stimulated with 500 ng/ml lipopolysaccharide (LPS) and 100 ng/ml interferon-γ (IFN-γ), while the M2-polarized and nAgB-treated M2-polarized groups were stimulated with 100 ng/ml interleukin-4 (IL-4) and 100 ng/ml IL-13. Cells and culture supernatants were collected from all groups. The relative mRNA transcription levels of macrophage polarization markers, STAT6, and PPAR-γ were detected by qPCR. The relative protein expression levels of relevant markers were measured by Western blotting, and the concentrations of related cytokines in the supernatant were determined by ELISA. Results CCK8 assay results at 24 hours showed that cell viability in the 1, 4, 16, and 64 μg/ml nAgB-treated groups (1.41 ± 0.09, 1.62 ± 0.08, 1.78 ± 0.04, 1.90 ± 0.04, respectively) was significantly higher than in the 0 μg/ml group (1.07 ± 0.05) (t = 8.67, 14.57, 27.43, 31.87; all P < 0.01). EdU assay results indicated that the cell proliferation capacity in the 1, 4, 16, and 64 μg/ml nAgB-treated groups (0.65 ± 0.01, 0.78 ± 0.02, 0.89 ± 0.02, 0.99 ± 0.02, respectively) was significantly higher than in the 0 μg/ml group (0.47 ± 0.02) (t = 16.21, 20.58, 33.47, 39.43; all P < 0.01). qPCR results showed that the relative mRNA levels of inducible nitric oxide synthase (iNOS), IL-6, and IL-1β in the nAgB-treated M1-polarized group (3.23 ± 0.92, 1.56 ± 0.58, 19.87 ± 0.35) were significantly lower than those in the M1-polarized group (10.62 ± 1.68, 3.97 ± 0.25, 24.40 ± 0.03) (t = 6.69, 6.62, 22.07; all P < 0.01). Conversely, the relative mRNA level of Arg-1 in the nAgB-treated M2-polarized group (29.30 ± 2.92) was significantly higher than that in the M2-polarized group (14.94 ± 0.77) (t = 8.23, P < 0.01). The relative mRNA levels of STAT6 and PPAR-γ in the nAgB group (59.12 ± 3.03, 7.82 ± 0.50) were significantly higher than those in the control group (26.38 ± 1.89, 3.71 ± 0.17) (t = 15.90, 13.40; both P < 0.01), in the nAgB-treated M1-polarized group (40.73 ± 2.91, 4.19 ± 0.88) were higher than in the M1-polarized group (17.93 ± 1.90, 1.76 ± 0.08) (t = 11.37, 4.75; both P < 0.01), and in the nAgB-treated M2-polarized group (140.50 ± 5.64, 11.67 ± 0.80) were higher than in the M2-polarized group (37.55 ± 5.92, 6.87 ± 0.28) (t = 21.82, 9.84; both P < 0.01). Western blotting results showed that the relative protein expression of iNOS in the nAgB-treated M1-polarized group (0.60 ± 0.02) was significantly lower than in the M1-polarized group (1.02 ± 0.03) (t = 21.86, P < 0.01), while the expression of CD206 in the nAgB-treated M2-polarized group (1.03 ± 0.04) was significantly higher than in the M2-polarized group (0.84 ± 0.02) (t = 7.78, P < 0.01). The relative protein levels of p-STAT6 and PPAR-γ in the nAgB group (0.76 ± 0.03, 0.77 ± 0.02) were significantly higher than in the control group (0.55 ± 0.05, 0.37 ± 0.00) (t = 6.11, P < 0.05; t = 40.16, P < 0.01), in the nAgB-treated M1-polarized group (0.60 ± 0.01, 0.42 ± 0.04) were higher than in the M1-polarized group (0.39 ± 0.05, 0.18 ± 0.01) (t = 6.64, 10.06; both P < 0.01), and in the nAgB-treated M2-polarized group (1.12 ± 0.11, 0.94 ± 0.02) were higher than in the M2-polarized group (0.86 ± 0.05, 0.66 ± 0.00) (t = 3.71, 28.18; both P < 0.01). ELISA results revealed that the secretion of TGF-β1 and IL-10 in the nAgB group [(70.27 ± 4.57), (167.00 ± 29.27) pg/ml] was significantly higher than in the control group [(29.87 ± 2.24), (50.17 ± 8.99) pg/ml] (t = 13.76, 6.61; both P < 0.01). In the nAgB-treated M1-polarized group, the levels of TNF-α and IL-1β [(523.20 ± 6.72), (387.80 ± 3.84) pg/ml] were significantly lower, while the levels of TGF-β1 and IL-10 [(47.15 ± 0.98), (137.30 ± 9.80) pg/ml] were significantly higher, compared to the M1-polarized group, [(995.70 ± 9.92), (680.90 ± 3.33) pg/ml] and [(18.05 ± 0.57), (21.66 ± 0.07) pg/ml], respectively (t = 68.32, 99.90, 44.41, 20.44; all P < 0.01). Similarly, nAgB-treated M2-polarized group,the levels of TNF-α and IL-1β [(398.50 ± 2.57), (85.18 ± 5.14) pg/ml] were significantly lower, while the levels of TGF-β1 and IL-10 [(293.20 ± 15.09), (341.20 ± 77.94) pg/ml] were significantly higher, compared to the M2-polarized group [(578.70 ± 12.36), (157.60 ± 14.25) pg/ml] and [(167.20 ± 20.34), (72.44 ± 5.28) pg/ml], respectively (t = 24.71, 8.28, 8.62, 5.82; all P < 0.01). Conclusion nAgB promotes macrophage polarization towards the M2 phenotype and suppresses the M1 response. This immunomodulatory effect is potentially mediated through the activation of the STAT6/PPAR-γ signaling pathway.

Key words: Echinococcus granulosus antigen B, Macrophage polarization, STAT6, PPAR-γ

CLC Number:

R383.33

CAO Li, YANG Xuehua, JIAO Hongjie, HE Baiqifeng, ZHANG Yunfei, YUE Yingbin, CHENG Yongfeng, WANG Jiajing, SONG Haichen, YAN Mei. Echinococcus granulosus native antigen B regulating macrophage polarization through the STAT6/PPAR-γ signaling pathway in vitro[J]. CHINESE JOURNAL OF PARASITOLOGY AND PARASITIC DISEASES, 2025, 43(5): 627-634.

Figures/Tables 8

Table 2

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

References 35

[1]	Nobs SP, Kopf M. Tissue-resident macrophages: Guardians of organ homeostasis[J]. Trends Immunol, 2021, 42(6): 495-507.
[2]	Xu MM, Wei SY, Su T, et al. Visualizing macrophage polarization through fluorescent mRNA profiling[J]. Biosensors (Basel), 2024, 14(10): 475.
[3]	Luo M, Zhao FK, Cheng H, et al. Macrophage polarization: An important role in inflammatory diseases[J]. Front Immunol, 2024, 15: 1352946.
[4]	Strizova Z, Benesova I, Bartolini R, et al. M1/M2 macrophages and their overlaps - myth or reality?[J]. Clin Sci (Lond), 2023, 137(15): 1067-1093.
[5]	Yan LF, Wang J, Cai X, et al. Macrophage plasticity: Signaling pathways, tissue repair, and regeneration[J]. Med Comm (2020), 2024, 5(8): e658.
[6]	Li M, Wang MJ, Wen YJ, et al. Signaling pathways in macrophages: Molecular mechanisms and therapeutic targets[J]. Med Comm (2020), 2023, 4(5): e349.
[7]	Lee YJ, Kim BM, Ahn YH, et al. STAT6 signaling mediates PPARγ activation and resolution of acute sterile inflammation in mice[J]. Cells, 2021, 10(3): 501.
[8]	刘白雪, 蒉嫣, 薛垂召, 等. 2023年全国棘球蚴病防治工作进展[J]. 中国寄生虫学与寄生虫病杂志, 2025, 43(1): 6-13.
	Liu BX, Kui Y, Xue CZ, et al. Progress of the national echinococcosis control programme in China, 2023[J]. Chin J Parasitol Parasit Dis, 2025, 43(1): 6-13. (in Chinese)
[9]	Zhou HR, Wang XL, Han S, et al. Advances and challenges in the prevention, control and research of echinococcosis in China[J]. Decod Infect Transm, 2025, 3: 100041.
[10]	Wang Y, Ma BC, Wang LY, et al. Effects of management of infection source of echinococcosis in Linzhi, Tibet Autonomous Region of China[J]. Infect Dis Poverty, 2021, 10: 25.
[11]	Qian YY, Huang FF, Chen SY, et al. Therapeutic effect of recombinant Echinococcus granulosus antigen B subunit 2 protein on sepsis in a mouse model[J]. Parasit Vectors, 2024, 17(1): 467.
[12]	da Silva ED, Cancela M, Monteiro KM, et al. Antigen B from Echinococcus granulosus enters mammalian cells by endocytic pathways[J]. PLoS Negl Trop Dis, 2018, 12(5): e0006473.
[13]	焦红杰, 齐文静, 郭刚, 等. 细粒棘球蚴抗原B对小鼠巨噬细胞RAW264.7的极化作用[J]. 中国寄生虫学与寄生虫病杂志, 2023, 41(1): 23-28.
	Jiao HJ, Qi WJ, Guo G, et al. Polarization effect of Echinococcus granulosus antigen B on the mouse macrophage RAW264.7[J]. Chin J Parasitol Parasit Dis, 2023, 41(1): 23-28. (in Chinese)
[14]	Tawfeek GM, Elwakil HS, El-Hoseiny L, et al. Comparative analysis of the diagnostic performance of crude sheep hydatid cyst fluid, purified antigen B and its subunit (12 Kda), assessed by ELISA, in the diagnosis of human cystic echinococcosis[J]. Parasitol Res, 2011, 108(2): 371-376.
[15]	Zhang YF, Yue YB, Cheng YF, et al. Antigen B from Echinococcus granulosus regulates macrophage phagocytosis by controlling TLR4 endocytosis in immune thrombocytopenia[J]. Chem Biol Interact, 2025, 406: 111350.
[16]	Silva-álvarez V, Folle AM, Ramos AL, et al. Echinococcus granulosus Antigen B binds to monocytes and macrophages modulating cell response to inflammation[J]. Parasit Vectors, 2016, 9: 69.
[17]	Bao JL, Qi WJ, Sun C, et al. Echinococcus granulosus sensu stricto and antigen B may decrease inflammatory bowel disease through regulation of M1/2 polarization[J]. Parasit Vectors, 2022, 15(1): 391.
[18]	Lee KY. M1 and M2 polarization of macrophages: A mini-review[J]. Med Biol Sci Eng, 2019, 2(1): 1-5.
[19]	Yao YL, Xu XH, Jin LP. Macrophage polarization in physiological and pathological pregnancy[J]. Front Immunol, 2019, 10: 792.
[20]	Ishida K, Nagatake T, Saika A, et al. Induction of unique macrophage subset by simultaneous stimulation with LPS and IL-4[J]. Front Immunol, 2023, 14: 1111729.
[21]	Zhu JF, Xu ZP, Chen XJ, et al. Parasitic antigens alter macrophage polarization during Schistosoma japonicum infection in mice[J]. Parasit Vectors, 2014, 7: 122.
[22]	Zhou L, Dang Z, Wang SY, et al. Transcription factor STAT enhanced antimicrobial activities in Bombyx mori[J]. Int J Biol Macromol, 2024, 254(Pt 2): 127637.
[23]	Xue C, Yao QF, Gu XY, et al. Evolving cognition of the JAK-STAT signaling pathway: Autoimmune disorders and cancer[J]. Signal Transduct Target Ther, 2023, 8(1): 204.
[24]	Shi JH, Liu LN, Song DD, et al. TRAF3/STAT6 axis regulates macrophage polarization and tumor progression[J]. Cell Death Differ, 2023, 30(8): 2005-2016.
[25]	Blackler G, Yue LZ, Klapak J, et al. Targeting STAT6-mediated synovial macrophage activation improves pain in experimental knee osteoarthritis[J]. Arthritis Res Ther, 2024, 26(1): 73.
[26]	Zhang YQ, Li B, Gu WH, et al. Hepatoma cell-derived exosomal SNORD52 mediates M2 macrophage polarization by activating the JAK2/STAT6 pathway[J]. Discov Oncol, 2025, 16(1): 36.
[27]	Yan SW, Zhang R, Guo X, et al. Trichinella spiralis dipeptidyl peptidase 1 suppressed macrophage cytotoxicity by promoting M2 polarization via the STAT6/PPARγ pathway[J]. Vet Res, 2023, 54(1): 77.
[28]	Szanto A, Balint BL, Nagy ZS, et al. STAT6 transcription factor is a facilitator of the nuclear receptor PPARγ-regulated gene expression in macrophages and dendritic cells[J]. Immunity, 2010, 33(5): 699-712.
[29]	Qiu YH, Gan ML, Wang XY, et al. The global perspective on peroxisome proliferator-activated receptor γ (PPARγ) in ectopic fat deposition: A review[J]. Int J Biol Macromol, 2023, 253(Pt 5): 127042.
[30]	Okreglicka K, Iten I, Pohlmeier L, et al. PPARγ is essential for the development of bone marrow erythroblastic island macrophages and splenic red pulp macrophages[J]. J Exp Med, 2021, 218(5): e20191314.
[31]	Shao X, Xu PC, Ji LL, et al. Low-dose decitabine promotes M2 macrophage polarization in patients with primary immune thrombocytopenia via enhancing KLF4 binding to PPARγ promoter[J]. Clin Transl Med, 2023, 13(7): e1344.
[32]	Gopalakrishnan A, Joseph J, Shirey KA, et al. Protection against influenza-induced Acute Lung Injury (ALI) by enhanced induction of M2a macrophages: Possible role of PPARγ/RXR ligands in IL-4-induced M2a macrophage differentiation[J]. Front Immunol, 2022, 13: 968336.
[33]	Reddy SS, Agarwal H, Jaiswal A, et al. Macrophage p47^phox regulates pressure overload-induced left ventricular remodeling by modulating IL-4/STAT6/PPARγ signaling[J]. Free Radic Biol Med, 2021, 168: 168-179.
[34]	Xue L, Wu YY. Activation of PPARγ regulates M1/M2 macrophage polarization and attenuates dextran sulfate sodium salt-induced inflammatory bowel disease via the STAT-1/STAT-6 pathway[J]. Kaohsiung J Med Sci, 2025, 41(2): e12927.
[35]	Lee YJ, Kim K, Kim M, et al. Inhibition of STAT6 activation by AS1517499 inhibits expression and activity of PPARγ in macrophages to resolve acute inflammation in mice[J]. Biomolecules, 2022, 12(3): 447.

基因 Gene	引物序列（5'→3'） Primer sequence (5′→3′)
STAT6	F：CTCTGTGGGGCCTAATTTCCA
	R：CATCTGAACCGACCAGGAACT
PPAR-γ	F：GCCCTTTGGTGACTTTATGG
	R：CAGCAGGTT GTCTTGGATGT
iNOS	F：CAACAGGGAGAAAGCGCAAA
	R：TGATGGACCCCAAGCAAGAC
IL-6	F：GCCTTCTTGGGACTGATGCT
	R：TGTGACTCCAGCTTATCTCTTGG
IL-1β	F：TGCCACCTTTTGACAGTGATG
	R：ATGTGCTGCTGCGAGATTTG
Arg-1	F：GTGGGGAAAGCCAATGAAG
	R：GCTTCCA ACTGCCAGACTGT
GAPDH	F：AACCCTTAAGAGGGATGCTGC
	R：TCTACGGGACGAGGAAACAC
