Immunogenecity of recombinant Leishmania donovani Peroxidoxin-1, tryparedoxin peroxidase, hypothetical protein CAJ07026.1 and GDP-mannose pyrophosphorylase in BALB/c mice

Abstract

Abstract:

Objective To evaluate the immune responses to recombinant Leishmania donovani peroxidoxin-1(Pxn1), tryparedoxin peroxidases(TryP), hypothetical protein CAJ07026.1(Hyp07026) and GDP-mannose pyrophosphorylase(GDPMP) in BALB/c mice.Methods The genes of L.donovani Pxn1, TryP, Hyp07026 and GDPMP were amplified by RT-PCR separately, and cloned into plasmid pQE30 to construct recombinant pQE30-Pxn1, pQE30-TryP, pQE30-Hyp07026 and pQE30-GDPMP, respectively.They were then transfected into Escherichia coli for expression under IPTG induction.rPxn1 and rTryP were purified with the NTA-Ni purification system under native condition, while rHyp07026 and rGDPMP were purified with the same system under denaturing condition.Then the recombinant proteins were used to immunize BALB/c mice (n = 5 for each) for 4 times and PBS was used as a control (n = 5).After that, RNA was extracted from spleen cells, and the transcriptional profiling of cytokines was examined by qRT-PCR microarray.Results PCR amplification of Pxn1, TryP, Hyp07026 and GDPMP produced fragments of 570, 610, 1 040 and 1 200 bp, respectively, sequences of which were consistent with those in GenBank as confirmed by the sequencing results.All of them were highly expressed in E.coli under IPTG induction, with molecular weights of 22 000, 23 000, 38 000 and 45 000 for rPXNT1, rTXNT, rHyp07026 and rGDPMP, respectively.Among the mRNAs of 84 cytokine genes expressed in the spleen cells of the BALB/c mice immunized with rGDPMP, rPXNT1, rTXNT and rHyp07026, significantly higher mRNA levels of IL-1f6( 96.22, 271.54, 108.51 and 250.15, respectively ), IL-17f (105.54, 35.71, 53.38 and 53.57, respectively ) and IL-10 (21.68, 27.51, 24.45 and 2.91, respectively ) were found in comparison to PBS control, with significantly lower mRNA levels of IL-4 (5.74, 2.43, 1.59 and 0.76, respectively), IL-12β (0.05, 0.26, 0.10 and 0.50, respectively), IL-18 (0.12, 0.21, 0.13 and 0.04, respectively ) and IFN-γ(3.59, 0.39, 0.29 and 0.63, respectively).Conclusion The findings suggest that the rTryP, rPxn1, rHyp07026 and rGDPMP of L.donovani can stimulate inflammatory responses and induce immune suppression.

Key words: Leishmania donovani, Peroxidoxin-1, Tryparedoxin peroxidase, Hypothetical protein CAJ07026.1, GDP-mannose pyrophosphorylase, Immunogenecity

CLC Number:

R382.22

Bao-qian JING, Yong-en XIE, Wei-min HU, Jian YANG, Chao-li WANG, Li FENG. Immunogenecity of recombinant Leishmania donovani Peroxidoxin-1, tryparedoxin peroxidase, hypothetical protein CAJ07026.1 and GDP-mannose pyrophosphorylase in BALB/c mice[J]. CHINESE JOURNAL OF PARASITOLOGY AND PARASITIC DISEASES, 2017, 35(6): 563-569.

Figures/Tables 4

Table 1

Fig.1

Fig.2

Table 2

Cytokine expression fold-change in mouse spleen cells stimulated with recombinant rPxn1, rTryP, rHyp07026 and rGDPMP from Leishmania donovani in comparison to PBS group

基因标志 Gene symbol	重组过氧化物还原酶1 rPxn1		重组锥虫氧化还原过氧化物酶rTryP		重组假定蛋白 rHyp07026		重组GDP-甘露糖焦磷酸化酶rGDPMP
基因标志 Gene symbol	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value
Bmp1	1.97	0.037 5	1.23	0.569 2	0.75	0.442 0	0.59	0.509 0
Bmp10	5.21	0.068 9	3.01	0.090 7	8.34	0.001 5	2.45	0.179 2
Bmp2	0.87	0.600 5	0.15	0.015 0	0.28	0.016 2	0.16	0.076 6
Bmp3	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.67	0.001 6
Bmp4	0.39	0.115 6	0.25	0.005 4	0.06	0.000 4	0.28	0.005 2
Bmp5	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.67	0.001 6
Bmp6	0.56	0.065 5	0.42	0.008 6	0.04	0.006 0	0.21	0.003 5
Bmp7	0.60	0.416 6	0.42	0.018 3	0.07	0.000 0	0.45	0.006 1
Bmp8b	1.90	0.119 0	0.60	0.320 0	0.91	0.830 9	0.31	0.067 8
Csf1	3.01	0.000 4	1.93	0.002 6	1.44	0.020 6	1.84	0.022 9
Csf2	2.06	0.014 4	1.63	0.273 8	4.27	0.004 0	6.55	0.001 2
Ctf1	8.85	0.018 5	1.28	0.734 8	2.98	0.244 2	3.13	0.106 4
Ctf2	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.67	0.001 8
Fasl	0.67	0.052 6	0.53	0.019 0	3.40	0.002 0	0.61	0.237 4
Fbrs	1.15	0.026 6	0.97	0.763 1	1.30	0.026 4	0.70	0.003 7
Fgf10	1.10	0.254 0	1.46	0.003 5	2.53	0.054 1	0.67	0.001 6
Flt3l	0.59	0.000 2	0.60	0.000 0	0.41	0.216 8	0.52	0.000 0
Gdf1	0.85	0.440 9	1.08	0.610 3	1.38	0.148 2	0.45	0.010 1
Gdf10	0.31	0.077 3	0.17	0.000 4	0.26	0.030 0	0.08	0.000 1
Gdf11	0.21	0.000 0	0.22	0.000 3	0.01	0.000 1	0.15	0.000 1
Gdf15	18.79	0.000 0	12.28	0.000 2	14.96	0.000 1	2.47	0.015 4
Gdf2	0.96	0.900 2	1.03	0.923 6	0.98	0.952 9	0.65	0.361 8
Gdf3	0.99	0.960 6	0.23	0.073 9	0.81	0.547 4	0.58	0.131 5
Gdf5	2.15	0.175 9	3.99	0.014 7	1.91	0.184 5	0.95	0.926 7
Mstn	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.67	0.001 6
Gdf9	0.77	0.375 3	0.78	0.623 9	0.17	0.000 2c	0.51	0.185 5
Ifna2	1.47	0.622 5	1.74	0.276 0	1.21	0.546 0	0.96	0.932 1
Ifna4	3.34	0.195 6	1.87	0.408 5	0.80	0.702 2	1.29	0.725 3
Ifnb1	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2c	0.84	0.117 5
Ifng	0.39	0.000 2	0.29	0.000 8	0.63	0.007 8c	3.59	0.000 1
Il10	27.51	0.000 0	24.45	0.000 0	2.91	0.007 9c	21.68	0.000 0
Il11	1.64	0.167 9	1.42	0.024 2	1.55	0.055 1	0.93	0.827 6
Il12b	0.26	0.014 1	0.10	0.037 7	0.50	0.583 8	0.05	0.002 2
Il13	2.23	0.015 5	1.60	0.087 7	2.10	0.004 8	5.84	0.000 3
Il15	0.97	0.857 8	0.78	0.161 1	0.09	0.000 1	0.76	0.107 8
Il16	0.38	0.019 3	0.30	0.012 7	0.50	0.054 8	0.19	0.007 4
Il17b	1.03	0.976 4	1.06	0.923 8	1.81	0.413 6	0.55	0.336 5
Il17c	1.65	0.331 5	0.54	0.256 5	1.03	0.975 5	0.37	0.122 0
Il25	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.67	0.001 6
Il17f	35.71	0.000 1	53.38	0.000 0	53.57	0.000 0	105.54	0.000 0
Il18	0.21	0.000 0	0.13	0.000 2	0.04	0.002 9	0.12	0.000 0
Il19	15.33	0.000 1	7.00	0.012 8	2.17	0.109 7	3.45	0.000 7
Il1a	16.02	0.000 1	9.46	0.000 3	4.77	0.001 4	20.18	0.000 1
Il1b	9.44	0.000 0	4.50	0.000 2	3.66	0.001 5	2.56	0.002 4
Il1f10	3.31	0.112 4	4.00	0.059 8	1.50	0.002 2	1.90	0.116 6
Il1f5	3.30	0.162 5	2.92	0.081 9	1.23	0.365 5	1.17	0.853 2
基因标志 Gene symbol	重组过氧化物还原酶1 rPxn1		重组锥虫氧化还原过氧化物酶rTryP		重组假定蛋白Hyp07026rHyp07026		重组GDP-甘露糖焦磷酸化酶rGDPMP
基因标志 Gene symbol	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value	变化倍数 Fold-change	P值 P value
Il1f6	271.54	0.000 0	108.51	0.000 0	250.15	0.000 0	96.22	0.000 0
Il1f8	2.62	0.129 9	1.72	0.020 4	2.32	0.113 2	0.67	0.001 6
Il1f9	19.45	0.000 0	11.33	0.000 0	48.73	0.000 0	6.11	0.000 1
Il1rn	47.01	0.000 0	37.40	0.000 0	24.03	0.000 1	17.77	0.000 1
Il2	6.60	0.016 1	3.27	0.0813	5.23	0.036 7	2.52	0.197 0
Il20	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2	0.90	0.727 6
Il21	3.34	0.008 8	1.55	0.237 0	13.00	0.000 5	3.58	0.016 9
Il24	0.15	0.000 0	0.16	0.000 1	0.01	0.000 0	0.11	0.000 0
Il27	3.12	0.000 6	2.69	0.002 9	8.36	0.000 1	2.69	0.000 7
Il3	41.02	0.000 0	14.27	0.000 6	5.79	0.005 9	83.96	0.000 0
Il4	2.43	0.016 9	1.59	0.197 1	0.71	0.379 8	5.74	0.000 6
Il7	1.10	0.254 0	1.46	0.003 5	2.38	0.138 4	0.67	0.001 6
Il9	1.10	0.254 0	1.46	0.003 5	1.50	0.002 2c	0.84	0.506 2
Inha	2.32	0.086 2	3.32	0.045 1	0.43	0.200 9	4.76	0.015 9
Inhba	30.95	0.000 1	20.46	0.000 1	35.51	0.000 1	24.00	0.000 2
Lefty1	0.50	0.004 8	0.51	0.016 9	0.32	0.000 5	0.36	0.002 1
Lif	51.33	0.000 3	33.09	0.000 5	10.65	0.004 4	46.05	0.000 6
Lta	0.44	0.000 3	0.24	0.002 3	0.59	0.004 6	0.58	0.004 3
Ltb	0.18	0.000 0	0.14	0.000 0	0.26	0.000 0	0.14	0.000 0
Mif	1.93	0.002 1	1.92	0.003 1	3.65	0.000 2	1.98	0.003 2
Scgb3a1	11.22	0.0108	6.89	0.021 7	5.66	0.057 5	3.19	0.113 3
Scye1	0.99	0.922 4	1.05	0.661 3	1.84	0.009 6	1.02	0.593 3
Tnf	3.58	0.031 6	1.07	0.878 5	1.69	0.246 2	0.87	0.847 0
Tnfrsf11b	9.09	0.003 9	2.30	0.288 8	2.54	0.103 9	6.78	0.016 0
Tnfsf10	0.74	0.000 9	0.74	0.024 3	0.75	0.004 7	0.72	0.000 1
Tnfsf11	0.88	0.638 9	0.66	0.105 0	0.18	0.002 5	0.71	0.264 2
Tnfsf12	1.32	0.008 7	0.76	0.046 4	1.39	0.0340	1.17	0.049 6
Tnfsf13	0.51	0.017 5	0.24	0.001 4	2.69	0.004 6	0.35	0.008 7
Tnfsf13b	0.71	0.005 2	0.57	0.003 1	0.32	0.002 3	0.44	0.012 8
Tnfsf14	0.92	0.457 2	0.65	0.016 0	0.74	0.065 3	0.65	0.056 8
Tnfsf15	2.87	0.260 5	1.53	0.631 9	1.43	0.642 8	1.21	0.807 2
Tnfsf18	1.60	0.145 2	1.52	0.355 5	0.56	0.110 7	0.96	0.882 3
Tnfsf4	0.53	0.026 5	0.46	0.056 8	0.26	0.004 0	0.50	0.001 7
Cd40lg	0.56	0.019 9	0.45	0.007 9	0.40	0.006 4	0.39	0.000 8
Cd70	14.37	0.000 0	9.77	0.000 1	0.34	0.000 7	9.20	0.000 2
Tnfsf8	2.28	0.017 4	1.44	0.169 9	2.07	0.043 7	2.07	0.039 8
Tnfsf9	5.46	0.009 2	4.15	0.013 3	3.03	0.033 7	1.95	0.225 4
Txlna	0.90	0.798 3	0.69	0.403 9	0.80	0.599 9	0.39	0.159 0
Gusb	1.66	0.058 2	1.10	0.654 8	2.83	0.010 3	1.21	0.572 7
Hprt1	1.06	0.250 5	1.28	0.001 3	0.82	0.0162	0.99	0.820 4
Hsp90ab1	0.94	0.250 5	0.78	0.001 3	1.22	0.016 2	1.01	0.820 4
Gapdh	1.18	0.009 0	1.00	0.799 4	1.72	0.000 2	1.62	0.000 0
Actb	0.74	0.061 2	0.59	0.009 8	0.84	0.239 0	0.53	0.004 3
Bmp1	1.97	0.061 2	1.23	0.061 1	0.75	0.009 8	0.59	0.004 3

Table 2

References 25

[1]	赵桂华, 王洪法, 仲维霞, 等.新疆喀什地区黑热病暴发的危险因素分析[J].中国人兽共患病学报, 2015, 31(6): 592-596.
[2]	敬保迁, 张仁刚, 邓世山, 等.杜氏利什曼原虫前鞭毛体与无鞭毛体的比较蛋白质组学研究[J].中国寄生虫学与寄生虫病杂志, 2009, 27(2): 102-106.
[3]	da Fonseca Pires S, Fialho LC Jr, Silva SO, et al.Identification of virulence factors in Leishmania infantum strains by a proteomic approach.[J].J Proteome Res, 2014, 13(4): 1860-1872.
[4]	Henard CA, Carlsen ED, Hay C, et al.Leishmania amazonensis amastigotes highly express a tryparedoxin peroxidase isoform that increases parasite resistance to macrophage antimicrobial defenses and fosters parasite virulence[J].PLoS Negl Trop Dis, 2014, 8(7): e3000.
[5]	Castro H, Teixeira F, Romao S, et al. Leishmania mitochondrial peroxiredoxin plays a crucial peroxidase-unrelated role during infection: insight into its novel chaperone activity[J].PLoS Pathog, 2011, 7(10): e1002325.
[6]	Teixeira F, Castro H, Cruz T, et al. Mitochondrial peroxiredoxin functions as crucial chaperone reservoir in Leishmania infantum[J].Proc Natl Acad Sci USA, 2015, 112(7): E616-E624.
[7]	Garami A.Disruption of mannose activation in Leishmania mexicana: GDP-mannose pyrophosphorylase is required for virulence, but not for viability[J].EMBO J, 2001, 20(14): 3657-3666.
[8]	Mao W, Daligaux P, Lazar N, et al. Biochemical analysis of leishmanial and human GDP-mannose pyrophosphorylases and selection of inhibitors as new leads[J].Sci Rep, 2017, 7(1): 751.
[9]	张仁刚, 张洁, 敬保迁.不同种株利什曼原虫前鞭毛体体外向无鞭毛体转化的研究[J].四川动物, 2009, 28(4), 488-492.
[10]	Espitia CM, Saldarriaga OA, Travi BL, et al. Transcriptional profiling of the spleen in progressive visceral leishmaniasis reveals mixed expression of type 1 and type 2 cytokine-responsive genes[J].BMC Immunol, 2014, 15: 38.
[11]	Mougneau E, Bihl F, Glaichenhaus N.Cell biology and immunology of Leishmania.[J].Immunol Rev, 2011, 240(1): 286-296.
[12]	Charmoy M, Hurrell BP, Romano A, et al. The Nlrp3 inflammasome, IL-1β, and neutrophil recruitment are required for susceptibility to a nonhealing strain of Leishmania major in C57BL/6 mice[J].Eur J Immuno, 2016, 46(4): 897-911.
[13]	Curry AJ, Kaye PM.Recombinant interleukin-1 alpha augments granuloma formation and cytokine production but not parasite clearance in mice infected with Leishmania donovani[J].Infect Immun, 1992, 60(10): 4422-4426.
[14]	Terrazas C, Varikuti S, Kimble J, et al. IL-17A promotes susceptibility during experimental visceral leishmaniasis caused by Leishmania donovani[J].FASEB J, 2016, 30(3): 1135-1143.
[15]	Lopez Kostka S, Dinges S, Griewank K, et al. IL-17 promotes progression of cutaneous leishmaniasis in susceptible mice[J].J Immunol, 2009, 182(5): 3039-3046.
[16]	Gonzalez-Lombana C, Gimblet C, Bacellar O, et al. IL-17 mediates immunopathology in the absence of IL-10 following Leishmania major infection[J].PLoS Pathog, 2013, 9(3): e1003243.
[17]	王健, 关望, 张仁刚, 等.杜氏利什曼原虫无鞭毛体表达抗原的Western Blot和MALDI-TO F/TOF分析[J].中国病原生物学杂志, 2014, 9(2): 135-139.
[18]	Bhattacharya P, Ghosh S, Ejazi SA, et al. Induction of IL-10 and TGFβ from CD4+CD25+FoxP3+ T cells correlates with parasite load in Indian Kala-azar patients infected with Leishmania donovani[J].PLoS Negl Trop Dis, 2016, 10(2): e0004422.
[19]	Girard-Madoux MJH, Kautz-Neu K, Lorenz B, et al. IL-10 signaling in dendritic cells attenuates anti-Leishmania major immunity without affecting protective memory responses[J].J Invest Dermatol, 2015, 135(11): 2890-2894.
[20]	Kamhawi S, Oliveira F, Vaenzuela JG.Using humans to make a human leishmaniasis vaccine[J].Sci Transl Med, 2014,6(234): 234fs18.
[21]	Carson C, Antoniou M, Ruiz-Argüello MB, et al. A prime/boost DNA/Modified vaccinia virus Ankara vaccine expressing recombinant Leishmania DNA encoding TRYP is safe and immunogenic in outbred dogs, the reservoir of zoonotic visceral leishmaniasis[J].Vaccine, 2009, 27(7): 1080-1086.
[22]	Daifalla NS, Bayih AG, Gedamu L.Differential immune response against recombinant Leishmania donovani peroxidoxin 1 and peroxidoxin 2 proteins in BALB/c mice[J].J Immunol Res, 2015, 2015: 1-11.
[23]	Núñez MC, Laurenti MD, Gómez-Sebastián S, et al. Head-to-head comparison of three vaccination strategies based on DNA and raw insect-derived recombinant proteins against Leishmania[J].PLoS One, 2012, 7(12): e51181.
[24]	Rodríguez-Cortés A, Ojeda A, López-Fuertes L, et al. Vaccination with plasmid DNA encoding KMPII, TRYP, LACK and GP63 does not protect dogs against Leishmania infantum experimental challenge[J].Vaccine, 2007, 25(46): 7962-7971.
[25]	敬昊东, 敬保迁.婴儿利什曼原虫细胞免疫优势抗原预测[J].川北医学院学报, 2016, 31(3): 310-314, 335.

基因名称 Gene name	引物序列5′→3′ Primer sequences5′→3′	酶切位点 Restriction site
Hyp07026	F： CGGATCCTACGCGGGCTTTCCGAGG	BamHⅠ
Hyp07026	R： GAAGCTTATTACAGGTCGCGCAG- CAACGAAG	HindⅢ
Pxn1	F： GGGATCCTCCTGCGGTGACGCCAAG	BamHⅠ
Pxn1	R： CAAGCTTATTACTTATTGTGATC- GACCTTCAGGCC	HindⅢ
TryP	F： GGG ATCCTCCTGCGGTAACGCCAAG	BamHⅠ
TryP	R： CAAGCTTATTACTGCTTGCTGAAG-TATCCCTCGAC	HindⅢ
GDPMP	F： GGGATGGTCTTCATCCGATGGCCAGG	BamHⅠ
GDPMP	R： CTTATTACATGATGATACCAGG- CTCGAAGTG
